Bovmatic Lite – Italian Semi-Automatic Pallet Wrapper with Mechanical Film Brake

Bovmatic: High-Quality Italian Pallet Wrappers

Bovmatic offers a range of high-performance pallet wrapping machines designed and manufactured in Italy, combining industrial-grade durability with user-friendly operation. Engineered for efficiency, safety, and reliability, Bovmatic machines are ideal for warehouses, production lines, and logistics centers seeking to optimize load stability and reduce packaging costs. Whether you’re looking for a simple mechanical solution or an advanced pre-stretch system, Bovmatic delivers Italian quality you can trust.

🇮🇹 Bovmatic Lite – Italian Semi-Automatic Pallet Wrapper with Mechanical Film Brake

Bovmatic Lite is a reliable, easy-to-use pallet wrapping machine designed for small and medium-sized businesses. Built on a proven Italian design (Evopac Nobel), this model has been adapted to meet the specific needs of the Polish and European markets. It’s perfect for logistics hubs, warehouses, and production facilities looking for a dependable entry-level solution.

🔧 Technical Specifications:

  • Turntable diameter: Ø 1650 mm
  • Max pallet size: up to 1200 × 1200 mm
  • Recommended pallet size: up to 800 × 1200 mm
  • Max load weight: 1200 kg
  • Max wrapping height: 2150 mm (H2200 column)
  • Turntable height: 75 mm
  • Rotation speed: 4–12 rpm (adjustable)
  • Film carriage: mechanical brake with adjustable tension
  • Lift/lower speed: 1.4–6 m/min
  • Photocell: automatic height detection
  • Control panel: LCD with membrane buttons
  • Power supply: 230 V / 50–60 Hz
  • Power consumption: 0.75–1.0 kW
  • Wrapping programs: 3 automatic + 1 manual
  • Productivity: up to 25 pallets/hour
  • Total dimensions: 2400 × 1650 × 2270 mm
  • Weight: approx. 310 kg

✅ Key Features:

  • Plug & Play installation (230 V, no 3-phase needed)
  • Soft start/stop for handling unstable loads
  • Automatic cycle start from 75 mm ground level
  • Service-friendly modular build with greasing system
  • Mechanical film brake carriage (standard), optional power pre-stretch carriage available
  • CE compliant: EN 12100, EN 60204-1, EN 61000-6-2/-6-4, 2006/42/EC Machinery Directive
  • Safety: emergency stop button, power isolation switch, mechanical guards with service key access
  • Error diagnostics system via display

📈 Why Choose Bovmatic Lite?

  • Affordable and robust
  • Extremely simple to operate – operator training takes under 10 minutes
  • Compatible with rental business models
  • Ideal for entry-level automation with optional film-saving upgrades
  • Perfect for seasonal projects or low-volume applications

📥 Documentation:

  • User Manual
  • Maintenance Guide
  • Electrical Schematics
  • Spare Parts Catalog
  • CE Declaration

📞 Contact us: kontakt@bovmatic.pl
📱 Learn more: +48 605 318 315

🚀 Bovmatic Pro – High-Performance Pre-Stretch Pallet Wrapper for Demanding Operations

Bovmatic Pro is a powerful, semi-automatic pallet wrapping machine equipped with an advanced pre-stretch system. Designed for high-demand environments, it offers precise control, energy efficiency, and unmatched wrapping consistency.

🔧 Technical Specifications:

  • Turntable diameter: Ø 1650 mm
  • Max pallet size: up to 1200 × 1200 mm
  • Recommended pallet size: up to 800 × 1200 mm
  • Max load weight: 1200 kg
  • Max wrapping height: 2450 mm (H2500 column)
  • Turntable height: 75 mm
  • Rotation speed: 5–12 rpm (adjustable)
  • Film carriage: powered pre-stretch up to 240%
  • Electronic film tension control from the panel
  • Lift/lower speed: 1.4–6 m/min
  • Photocell: automatic height detection
  • Control panel: LCD display with intuitive membrane keypad
  • Power supply: 230 V / 50–60 Hz
  • Power consumption: 0.75–1.0 kW
  • Wrapping programs: 3 automatic + 1 manual
  • Productivity: up to 30 pallets/hour
  • Total dimensions: 2400 × 1650 × 2640 mm
  • Weight: approx. 310 kg

🛡 Safety & Standards:

  • Emergency stop button (E-STOP)
  • Main power isolation switch
  • CE compliance: EN 12100, EN 60204-1, EN 61000-6-2/-6-4, 2006/42/EC Machinery Directive
  • Safety guards with lockout mechanism
  • System fault detection with error codes

⚙ Key Advantages:

  • Automated wrapping cycles for high throughput
  • Wide range of wrapping modes:
    • Up/Down
    • Up Only / Down Only
    • Dual Pallet Mode
    • Top Only
    • Layer-by-Layer
    • Reinforcement mode
  • Touch-based cycle editing and storage
  • Advanced control system with frequency inverters for all motors
  • Optional Top Press system for unstable or lightweight loads
  • Built-in diagnostics and programmable parameters

📥 Documentation:

  • User Manual
  • Operating Instructions
  • Parameters & Setup
  • Electrical Schematics
  • Spare Parts List
  • CE Declaration
